# Graphic approach to problems with inequalities

Author Message
TAGS:

### Hide Tags

Manager
Joined: 22 Jan 2010
Posts: 121
Followers: 2

Kudos [?]: 5 [0], given: 15

Re: Graphic approach to problems with inequalities [#permalink]

### Show Tags

22 Jan 2010, 20:26
Very interesting approach. I definitely need to practice this a bit before trying to use it on the exam.
Manager
Joined: 06 Jul 2010
Posts: 75
Followers: 1

Kudos [?]: 145 [0], given: 12

Re: Graphic approach to problems with inequalities [#permalink]

### Show Tags

02 Aug 2010, 10:02
sanjay_gmat wrote:
walker wrote:

There is another easier method to solve such questions. Let's take the same example to illustrate the method.

given : x > 2y

so we can write x = 2y + k where k is a positive number - equation 1

Fact 1 : x - y < 2

we can rewrite this as x -y + m =2 where m is a positive number - equation 2

solving equation 1 and equation 2

y = 2 -m - k AND x = 2 - m + y = (4 -2m -k)

=> 3x + 2y = 12 - 6m -3k + 4 - 2m - 2k = 16 -8m - 5k

so, 3x + 2y = 16 -8m -5k which is less than 18

now considering fact 2

Fact 2 : y - x < 2

we can rewrite this as y -x +m = 2 - equation 3

solving equation 1 and equation 3

y = m -2 -k and x = 2m -k -4

=> 3x + 2y = 8m -5k -16 which may or may not be less than 18 (since m and k may be of any positive value)

Hence A.

Is this method legitimate for inequalities? I've never heard of it and frankly I don't quite get it!

Help
Manager
Joined: 16 Feb 2010
Posts: 225
Followers: 2

Kudos [?]: 287 [0], given: 16

Re: Graphic approach to problems with inequalities [#permalink]

### Show Tags

30 Aug 2010, 13:27
Very useful, THANK YOU !
Director
Status: Apply - Last Chance
Affiliations: IIT, Purdue, PhD, TauBetaPi
Joined: 17 Jul 2010
Posts: 690
Schools: Wharton, Sloan, Chicago, Haas
WE 1: 8 years in Oil&Gas
Followers: 15

Kudos [?]: 147 [0], given: 15

Re: Graphic approach to problems with inequalities [#permalink]

### Show Tags

30 Aug 2010, 15:35
Can someone solve this without the graphical approach? Bunuel?
_________________

Consider kudos, they are good for health

Math Expert
Joined: 02 Sep 2009
Posts: 36520
Followers: 7066

Kudos [?]: 92918 [6] , given: 10528

Re: Graphic approach to problems with inequalities [#permalink]

### Show Tags

30 Aug 2010, 15:50
6
KUDOS
Expert's post
2
This post was
BOOKMARKED
mainhoon wrote:
Can someone solve this without the graphical approach? Bunuel?

My solution from: tough-inequality-challange-89225.html?hilit=walker%20graphic#p732298

If (x/y)>2, is 3x+2y<18?

(1) x-y is less than 2
(2) y-x is less than 2

$$\frac{x}{y}>2$$ tells us that $$x$$ and $$y$$ are either both positive or both negative, which means that all points $$(x,y)$$ satisfying given inequality are either in I or III quadrant. When they are both negative (in III quadrant) inequality $$3x+2y<18$$ is always true, so we should check only for I quadrant, or when both $$x$$ and $$y$$ are positive.

In I quadrant, as $$x$$ and $$y$$ are both positive, we can rewrite $$\frac{x}{y}>2$$ as $$x>2y>0$$ (remember $$x>0$$ and $$y>0$$).

So basically question becomes: If $$x>0$$ and $$y>0$$ and $$x>2y>0$$, is $$3x+2y<18$$?

(1) $$x-y<2$$.

Subtract inequalities $$x>2y$$ and $$x-y<2$$ (we can do this as signs are in opposite direction) --> $$x-(x-y)>2y-2$$ --> $$y<2$$.

Now add inequalities $$x-y<2$$ and $$y<2$$ (we can do this as signs are in the same direction) --> $$x-y+y<2+2$$ --> $$x<4$$.

We got $$y<2$$ and $$x<4$$. If we take maximum values $$x=4$$ and $$y=2$$ and substitute in $$3x+2y<18$$, we'll get $$12+4=16<18$$.

Sufficient.

(2) $$y-x<2$$ and $$x>2y$$:
$$x=3$$ and $$y=1$$ --> $$3x+2y=11<18$$ true.
$$x=11$$ and $$y=5$$ --> $$3x+2y=43<18$$ false.

Not sufficient.

_________________
Intern
Joined: 03 Sep 2010
Posts: 5
Followers: 0

Kudos [?]: 1 [0], given: 0

Re: Graphic approach to problems with inequalities [#permalink]

### Show Tags

27 Oct 2010, 22:24
Apologies for asking such a basic question - I'm afraid i haven't yet figured out how to draw these graphs accurately in the actual exam- I've heard you aren't permitted to take a ruler into the center.

How do you draw the figure for eg. x-y < 2 accurately enough to see that the equation passes through point P in your diag. ?
CEO
Joined: 17 Nov 2007
Posts: 3589
Concentration: Entrepreneurship, Other
Schools: Chicago (Booth) - Class of 2011
GMAT 1: 750 Q50 V40
Followers: 544

Kudos [?]: 3550 [0], given: 360

Re: Graphic approach to problems with inequalities [#permalink]

### Show Tags

28 Oct 2010, 03:24
akshey2021 wrote:
Apologies for asking such a basic question - I'm afraid i haven't yet figured out how to draw these graphs accurately in the actual exam- I've heard you aren't permitted to take a ruler into the center.

How do you draw the figure for eg. x-y < 2 accurately enough to see that the equation passes through point P in your diag. ?

Yes, you can't use a ruler. In many cases even if you don't draw accurate, you will see key points and areas. Then (like in 4. here) you can calculate for a couple of questionable points their precise positions.
_________________

HOT! GMAT TOOLKIT 2 (iOS) / GMAT TOOLKIT (Android) - The OFFICIAL GMAT CLUB PREP APP, a must-have app especially if you aim at 700+ | PrepGame

Intern
Status: Winning is not everything, but wanting to win is
Joined: 10 Nov 2010
Posts: 35
WE 1: IT Consultant (6Yr)
Followers: 0

Kudos [?]: 9 [0], given: 5

Re: Graphic approach to problems with inequalities [#permalink]

### Show Tags

19 Nov 2010, 15:44
Hi,

Maybe some help for these two questions (graphical method)

i) Is x.|y|>y^2 ?

a)x>y
b)y>0

ii) If x and y are non-zero integers and |x| + |y| = 32 what is xy?

a)-4x -12y = 0
b)|x| - |y| = 16

Thanks
Intern
Joined: 10 Jan 2011
Posts: 21
Location: India
Schools: ISB, IIM-A
WE 1: 4 yrs in finance
Followers: 0

Kudos [?]: 3 [0], given: 0

Re: Graphic approach to problems with inequalities [#permalink]

### Show Tags

17 Jan 2011, 10:16
I m not able to understand here one thing at while testing condition's one or two how came at conclusion that it is not sufficient or sufficient ???????
pls help me its really a bouncer to me

rahul
_________________

Rahul

Intern
Joined: 14 Dec 2010
Posts: 20
Followers: 0

Kudos [?]: 1 [0], given: 0

Re: Graphic approach to problems with inequalities [#permalink]

### Show Tags

18 Jan 2011, 10:05
Wow... never considered using linear programming technique's to solve for these. Going to use matrix algebra next ?

Posted from my mobile device
Intern
Joined: 02 May 2011
Posts: 6
Followers: 0

Kudos [?]: 1 [0], given: 0

Re: Graphic approach to problems with inequalities [#permalink]

### Show Tags

25 May 2011, 11:56
jsahni123 wrote:
Hi,

Maybe some help for these two questions (graphical method)

i) Is x.|y|>y^2 ?

a)x>y
b)y>0

ii) If x and y are non-zero integers and |x| + |y| = 32 what is xy?

a)-4x -12y = 0
b)|x| - |y| = 16

Thanks

Personally I think that if you an inequality with an absolute value, it is probably easier to just do it without the graphical method. In my opinion, if you really did want to graph an absolute value, I think you would have to keep in mind that |x| (where x is any value) is equal to sq root ((x)^2). With this being stated, I would rewrite the inequalities to reflect this and graph from there.

As an example, if I were to calculate the first question, this would be my approach:

1. Is x.|y|>y^2 ?

i. x>y
ii. y>0

In order for the inequality x|y| > y^2 to be true, either (a) y is -ve, and x is +ve or (b) both x and y are +ve. If (a) is the case, |x|>|y|. If (b) is the case, x>y. For an answer A, B, C, D, the statements (i) and (ii) must satisfy or not satisfy both statements (a) and (b). If statements (i) and (ii) satisfy only (a) OR (b), and not both, then the answer is E.

Statement (i): x>y. This is always true for case (b), but not (a). If y is -5 and x is -4, x>y, this violates the requirement that |x|>|y|, and the inequality is not true. Therefore not sufficient.

Statement (ii): Not sufficient because this does not tell us anything about x.

The answer would be C - x>y>0, as this satisfies the requirements we set out in (a) and (b).
Manager
Joined: 29 Jun 2011
Posts: 76
Followers: 3

Kudos [?]: 16 [0], given: 47

Re: Graphic approach to problems with inequalities [#permalink]

### Show Tags

02 Jul 2011, 03:55
walker wrote:
Hi all! My friend, Tarek, PM me and asked me to show how to use the graphic approach to problem with inequalities. I really love such approach because it is not only fast one after training, but also reliable. So, I try to illustrate how to use it.

1) If $$(x/y)>2$$, is $$3x+2y<18?$$

(1) $$x-y$$ is less than $$2$$
(2) $$y-x$$ is less than $$2$$

1. First of all, we draw x/y>2. x/y=2 - is a boundary. (see figure 1). we should note that if one of the variables is negative and other is positive, x/y will be always negative and less than 2. Therefore, our set of x,y that satisfied x/y>2 lies between line x/y=2 and x-axis.

2. Next, we draw our main inequality: 3x+2y<18. 3x+2y=18 - is a boundary. (see figure 2).

3. Now, we should combine our main inequality with the restriction, x/y>2. (see figure 3). Eventually, we defined two areas (sets) were the main inequality is TRUE and were it is FALSE. Two lines intersect in point P with coordinates: (4.5;2.25).

4. Let's consider fist condition: x-y<2. x-y=2 is a boundary. (see figure 4). As we can see all y,x that satisfies the fist condition lie in "green-TRUE" region. Therefore, the first statement is sufficient to answer the question. We should be careful and check where line x-y=2 passes point P, through left side or right side. We can put y=2.25 into x-y=2 and find that x=4.25<4.5 (left side). In other words, line x-y=2 passes y=2.25 (y-coordinate of P) early and goes above P.

5. Finally, let's check last condition: y-x<2. y-x=2 is a boundary. (see figure 5). As we can see all y,x that satisfies the second condition lie in both "green-TRUE" and "red-FALSE" regions. Thus, the second condition is insufficient.

This approach took less than 2 minutes.

Tips:

1) How fast can we draw a line, for example 3x+2y=18? Simple approach: we need two points to draw line, let's choose intersections with x- and y- axes. x=0 (intersection with y-axis) --> y=9; y=0 (intersection with x-axis) --> x=6.

2) Let's suppose we have a linear inequality, such as 38y-11x>121, suppose we've already drawn the line. How can we find what side is "true" and what side is "false"? The fastest method is just use y=0,x=-infinity. In our case, 0-(-infinity)=infinity>121 - true. Therefore, we take a left side.

That's all
Regards,
Serg a.k.a. Walker

Attachment:
The attachment tarek99.png is no longer available

i have a doubt...while plotting x/y>2...i multiplied both sides with y and got the inequality x>2y and followed nach0's rules... i got this graph...what am i missing here? whats wrong...?
Attachments

graph.png [ 12.14 KiB | Viewed 2523 times ]

_________________

It matters not how strait the gate,
How charged with punishments the scroll,
I am the master of my fate :
I am the captain of my soul.
~ William Ernest Henley

CEO
Joined: 17 Nov 2007
Posts: 3589
Concentration: Entrepreneurship, Other
Schools: Chicago (Booth) - Class of 2011
GMAT 1: 750 Q50 V40
Followers: 544

Kudos [?]: 3550 [1] , given: 360

Re: Graphic approach to problems with inequalities [#permalink]

### Show Tags

02 Jul 2011, 05:28
1
KUDOS
Expert's post
fivedaysleft wrote:
i have a doubt...while plotting x/y>2...i multiplied both sides with y and got the inequality x>2y .....

Your problem is a typical one for inequalities and modulus questions. You just forget to consider the case when y is negative.
Here is what you should do:

1. x/y >2
2. x >2y (y>0) & x <2y (y<0)
3. solve both inequalities BUT don't forget to apply conditions (y>0 and y<0). For example, in your plot y can't be negative.

By the way, try to check out whether the answer makes sense. Moreover, sometimes it's useful think a bit about expression at the beginning. For example, x/y > 2 only if x and y have the same sign. So, your last graph fails to pass this test.

Actually, that is why I used graphic approach as it allows to avoid such kind of mistakes.
_________________

HOT! GMAT TOOLKIT 2 (iOS) / GMAT TOOLKIT (Android) - The OFFICIAL GMAT CLUB PREP APP, a must-have app especially if you aim at 700+ | PrepGame

Manager
Joined: 29 Jun 2011
Posts: 76
Followers: 3

Kudos [?]: 16 [0], given: 47

Re: Graphic approach to problems with inequalities [#permalink]

### Show Tags

02 Jul 2011, 10:48
so thats what i was missing!
thanks a lot!
_________________

It matters not how strait the gate,
How charged with punishments the scroll,
I am the master of my fate :
I am the captain of my soul.
~ William Ernest Henley

Intern
Joined: 30 Nov 2010
Posts: 47
Followers: 0

Kudos [?]: 10 [1] , given: 27

Re: Graphic approach to problems with inequalities [#permalink]

### Show Tags

28 Jul 2011, 09:14
1
KUDOS
Bunuel wrote:
mainhoon wrote:
Can someone solve this without the graphical approach? Bunuel?

My solution from: tough-inequality-challange-89225.html?hilit=walker%20graphic#p732298

If (x/y)>2, is 3x+2y<18?

(1) x-y is less than 2
(2) y-x is less than 2

$$\frac{x}{y}>2$$ tells us that $$x$$ and $$y$$ are either both positive or both negative, which means that all points $$(x,y)$$ satisfying given inequality are either in I or III quadrant. When they are both negative (in III quadrant) inequality $$3x+2y<18$$ is always true, so we should check only for I quadrant, or when both $$x$$ and $$y$$ are positive.

In I quadrant, as $$x$$ and $$y$$ are both positive, we can rewrite $$\frac{x}{y}>2$$ as $$x>2y>0$$ (remember $$x>0$$ and $$y>0$$).

So basically question becomes: If $$x>0$$ and $$y>0$$ and $$x>2y>0$$, is $$3x+2y<18$$?

(1) $$x-y<2$$.

Subtract inequalities $$x>2y$$ and $$x-y<2$$ (we can do this as signs are in opposite direction) --> $$x-(x-y)>2y-2$$ --> $$y<2$$.

Now add inequalities $$x-y<2$$ and $$y<2$$ (we can do this as signs are in the same direction) --> $$x-y+y<2+2$$ --> $$x<4$$.

We got $$y<2$$ and $$x<4$$. If we take maximum values $$x=4$$ and $$y=2$$ and substitute in $$3x+2y<18$$, we'll get $$12+4=16<18$$.

Sufficient.

(2) $$y-x<2$$ and $$x>2y$$:
$$x=3$$ and $$y=1$$ --> $$3x+2y=11<18$$ true.
$$x=11$$ and $$y=5$$ --> $$3x+2y=43<18$$ false.

Not sufficient.

Sorry for being naive. Can you please to me the second part of the solution when you conclude it as "Not sufficient". How did you get the numbers 3, 1, 11,5 ?
Intern
Joined: 03 Sep 2010
Posts: 16
Followers: 2

Kudos [?]: 9 [0], given: 106

Re: Graphic approach to problems with inequalities [#permalink]

### Show Tags

28 Jul 2011, 23:16
walker wrote:

1. First of all, we draw x/y>2. x/y=2 - is a boundary. (see figure 1). we should note that if one of the variables is negative and other is positive, x/y will be always negative and less than 2. Therefore, our set of x,y that satisfied x/y>2 lies between line x/y=2 and x-axis.

[/url]

Hello Walker and everyone
I might sound really dumb here but just wanted to clarify a doubt as to WHY NOT any point in quadrant 1 and quadrant 3 relating to (X,Y) will give x/y>2. How did you calculate that the points "x/y>2 lies between line x/y=2 and x-axis."
I understood that both need to be negative or both the variables need to be Positive. But these values seem to be satisfied by points in whole of quadrant 1 and quadrant 3

Manager
Joined: 06 Apr 2011
Posts: 77
Location: India
GMAT 1: Q V
Followers: 0

Kudos [?]: 15 [0], given: 22

Re: Graphic approach to problems with inequalities [#permalink]

### Show Tags

08 Aug 2011, 06:30
Thanks walker for the super cool approach +zillion
_________________

Regards,
Asher

Intern
Joined: 10 Jun 2011
Posts: 6
Followers: 0

Kudos [?]: 0 [0], given: 0

Re: Graphic approach to problems with inequalities [#permalink]

### Show Tags

23 Sep 2011, 16:33
Is x > y?

(1) > y

(2) x3 > y

can some one solve this non linear which has x3 and sqrt (x) with graph method.
i need to decide on choosing on the graph method finally for my test. please help me..

if this is not feasible please suggest alternative options
Manager
Status: Trying hard to give another shot!
Joined: 29 Jun 2010
Posts: 119
GMAT Date: 12-19-2011
WE: Information Technology (Computer Software)
Followers: 1

Kudos [?]: 43 [0], given: 50

Re: Graphic approach to problems with inequalities [#permalink]

### Show Tags

23 Sep 2011, 20:14
_________________

Thanks,
GC24

Please click Kudos ,if my post helped you

Senior Manager
Joined: 23 Mar 2011
Posts: 473
Location: India
GPA: 2.5
WE: Operations (Hospitality and Tourism)
Followers: 19

Kudos [?]: 211 [0], given: 59

Re: Graphic approach to problems with inequalities [#permalink]

### Show Tags

18 Dec 2011, 02:58
_________________

"When the going gets tough, the tough gets going!"

Bring ON SOME KUDOS MATES+++

-----------------------------

My GMAT journey begins: http://gmatclub.com/forum/my-gmat-journey-begins-122251.html

Re: Graphic approach to problems with inequalities   [#permalink] 18 Dec 2011, 02:58

Go to page   Previous    1   2   3   4   5   6    Next  [ 116 posts ]

Similar topics Replies Last post
Similar
Topics:
2 Articles for solving quadratic equations using graphical approach 1 15 Sep 2016, 15:50
4 Ways to approach inequalities 4 16 Dec 2014, 06:17
39 Solving Quadratic Inequalities: Graphic Approach 3 23 Apr 2014, 10:57
2 inequality graphical approach, what to shade? see inside ... 2 25 Sep 2013, 04:28
Solving Inequalities Graphically: Is Graph Paper Allowed 7 25 Jan 2010, 08:42
Display posts from previous: Sort by
